USN 60 (retras din producţie)

Defectoscop portabil, complet digital, cu microprocesor, facilităţi pentru sudură, cu afişaj de mare rezoluţie. Scale DAC/TCG sau/şi AVG (DGS) electronice.

Caracteristici:

• Rugged USN durability
• 11 hours of battery operation
• Fast rotary knob operation
• Outstanding ultrasonic performance
• Extreme temperature use (-20°C to +55°C /-4°F to 130°F)
• Hi-resolution color LCD
• 4 selectable vibrant display color schemes to match lighting conditions
• Gates and gate functions color coded for easy identification
• Simple operation with fast rotary knob adjustments
• Auto CAL makes calibration fast & easy
• PRF (pulse repetition frequency) in spike mode: USN 60 = 15 Hz to 6 kHz; USN 60L = 15 Hz to 2 kHz
• 2 independent gates monitor amplitude and sound path distance for both flaw detection and thickness measurement applications
• 250 KHz to 25 MHz frequency range
• RF display mode enhances signal evaluation and bond inspection of dissimilar materials
• 4 selectable damping settings (50, 75, 150, 500 ohms) for optimum probe performance
• 1 mm to 28 m (0.040” to 1100”) range (in steel) covers thin to lengthy acoustically clean materials
• dB REF key evaluates subsequent echoes gain value and amplitude against the highest echo in Gate A when activated
• VGA Output provides an easy way to connect to a PC monitor or PC projector
• IF (Interface) Gate Option for automatic start of the display, Gate A, Gate B, and / or DAC / TCG for immersion testing applications
• RF Output Option outputs the raw RF waveform via a standard Lemo connector for further analysis
• BEA (Backwall Echo Attenuator) Option allows independent gain control of the region under Gate B for backwall echo monitoring
