SPYNE

Spyne™, an adaptable surface Eddy Current Array (ECA) screening tool, is specifically engineered to maximize productivity for the detection of Stress-Corrosion Cracking (SCC), cracks, subsurface defects, and pitting in various critical components such as high-pressure gas pipes, vessels, tanks, pipelines and more. With a higher PoD than MPI/PT and with its ultrafast capabilities, it paves the way to unprecedented efficiency.

Caracteristici

• Scan speed up to 600 mm/s (24 in/s)
• 200 mm (8 in) coverage in a single pass
• Infinite adjustments, from 150 mm (6 in) OD pipes to flat surfaces
• Grid-As-U-Go™ for quick and easy gridding
• Embedded and detachable spring-loaded encoder
• Ergonomic handles with acquisition control buttons
• Spring-loaded, interchangeable flexible probe
• Compatible with Reddy^® 128 or Ectane^®
• Use on high-temperature surfaces (up to 150ºC/302ºF)

  Specificații tehnice

  Scan speed

• Up to 600 mm/s (24 in/s)

• Coverage

• Up to 200 mm (8 in)

• Outer diameter range

• 150 mm (6 in) OD to flat surfaces

• Channels

• 128

• Materials

• Ferrous
• Non-ferrous

• Defect types

• Stress-Corrosion Cracking (SCC)
• Fatigue cracks
• Chloride SCC
• Surface cracks
• Subsurface cracks (non-ferrous materials)
• More

• Smallest detectable defects

• As small as 2 mm (0.080 in) L × 1 mm (0.040 in) D

• Liftoff tolerance

• Up to 3 mm (0.12 in)
• Non-conductive coatings and paints, with monitoring and auto-correction

• Operating temperature

• Up to 150ºC (302ºF)

• Cable

• 5 m (16.4 ft) or 10 m (32.8 ft)
